| Name: | Cube Ice Machine | Storage Capacity: | 1.5kg/150 Grain |
|---|---|---|---|
| Refrigerant: | R134A | Voltage: | 220v |
| Power(W): | 160W | Ice Storage Capacity: | 40kg |
| Ice Making At Every Turn: | 12 Grain | Weight: | 17kg |
| High Light: | 150 Grain Portable Ice Maker Machine,R134A Portable Ice Maker Machine,150 Grain small portable ice maker |
||
1. Cube ice machine features
cube ice machine are widely used in hotels, restaurants, bars, fast-food shops, supermarkets and cold drink shops, etc.
cube ice machine are highly efficient, energy saving, safe and environmentally friendly and are quickly becoming the most popular choice for clients around the world.
the ice peel off; it only takes as fast as 150-180 seconds.
The importation of water drain function makes ice cleaner and crystallizes the ice by draining out the water in the cold water tank.
2. Product advantage
a.Easy to operate
b.Stainless Structure
c.Automatic Protection
d.Elegant appearance
e. provide water filter free of charge
3.ice making process
· Intelligent Diagnostics: Monitors and records information for diagnosis and maintenance
· Easy Read Display: Alerts you when issues arise, and reminds you when regular cleaning and maintenance is needed
· Active Clean: Push of a button starts the cleaning process; automatically returns to ice production mode after cleaning cycle ends.
· Ice Assurance: Customizable ice production levels ensure ice is there when you need it and production is shut off when you don't
· Energy Management: Monitor and control energy and water consumption
Service and Support: Quick, accurate diagnosis of real-time data to keep operations running smoothly
5.ICE BIN
Bin has corrosion-resistant exterior with clear-coat finish that resists fingerprints and dirt. Seamless poly interior bin liner for easy cleanability. Patented Black hold-open hinged door design for added convenience. Internal ice scoop holder included.
4. Cube ice making machine Technical parameter
| Model no. |
Daily capacity (kgs/24h) |
Input power (W) |
Power supply |
Dimensions (L*W*H mm)
|
Refrigerant gas |
| BMC-30 | 30 | 320 | 220V/1P/50HZ | 430*520*790 | R134a |
| BMC-40 | 40 | 380 | 220V/1P/50HZ | 430*520*790 | R134a |
| BMC-60 | 60 | 400 | 220V/1P/50HZ | 530*600*820 | R134a |
| BMC-68 | 68 | 420 | 220V/1P/50HZ | 530*600*820 | R404a |
| BMC-90 | 90 | 600 | 220V/1P/50HZ | 680*690*1050 | R404a |
| BMC-126 | 126 | 650 | 220V/1P/50HZ | 680*690*1050 | R404a |
| BMC-160 | 160 | 800 | 220V/1P/50HZ | Ice maker560*630*550 | R404a |
| Ice bin 560*830*1000 | |||||
| BMC-180 | 180 | 850 | 220V/1P/50HZ | Ice maker 560*630*550 | R404a |
| Ice bin 560*830*1000 | |||||
| BMC-230 | 230 | 1180 | 220V/1P/50HZ | Ice maker 760*630*550 | R404a |
| Ice bin 760*830*1100 | |||||
| BMC-320 | 320 | 1350 | 220V/1P/50HZ | Ice maker 760*630*640 | R404a |
| Ice bin 760*830*1100 | |||||
| BMC-455 | 455 | 1860 | 220V/1P/50HZ | Ice maker 760*630*700 | R404a |
| Ice bin 760*830*1100 | |||||
| BMC-685 | 685 | 2800 | 380V/3P/50HZ | Ice maker1230*630*670 | R404a |
| Ice bin 1230*930*1240 | |||||
| BMC-910 | 910 | 3680 | 380V/3P/50HZ | Ice maker1230*630*700 | R404a |
| Ice bin 1230*930*1240 | |||||
| BMC-1500 | 1500 | 4500 | 380V/3P/50HZ | Ice maker1230*630*800 | R404a |
| Ice bin 1230*930*12 | |||||
|
Cube ice machine with bottom screw ice delivery system
|
|||||
| BMC-2T | 2000 | 10HP | 380V/3P/50HZ | 1500*1430*2070 | R404a |
| BMC-3T | 3000 | 15HP | 380V/3P/50HZ | 1800*1430*2070 | R404a |
| BMC-4T | 4000 | 20HP | 380V/3P/50HZ | 2100*1430*2070 | R404a |
| BMC-5T | 5000 | 25HP | 380V/3P/50HZ | 2400*1430*2070 |
R404a |
The features of the ice cube maker
♥Advanced microcomputer control system can make ice making and ice collecting process automatically. It has many kinds of protection functions which makes the ice maker convenient and safe to use
♥The core component of the ice maker is compressor which adopts the world famous brand,makes the performance of the ice maker more reliable and the energy consumption lower.
♥The refrigerating capacity of water-cooling type ice makeris stable, it is not affected by ambient temperature. It can make ice leisurely with enough output in hot summer.
The images of the ice cube maker
Can be use 2 model, and keep cooling about 5 hours.
Features & Details
[RAPID AND EFFICIENT ICE MAKING]- 440 lb (200 kg) per 24H capacity commercial ice maker realizes convenient and efficient ice making experience. 8*18 ice tray for 144 clear cubes one cycle in 12-18 minutes, each is 0.9" (22 mm) cubical, making it perfect for mixed drinks and bottles with small opening. 88 lb (40 kg) ice storage capacity for more flexible application. Heat insulation function prevents ice cubes from melting for 5-7 hours.
[SAFE AND HEALTHY]- Ultraviolet sterilizing lamp equipped to stop bacteria growth and meet your health needs. Ice cubes are crystal clear and thickness can be adjusted by modulating freezing time. This ice maker is sure to be a mighty addition to your business and home.
[MICROCOMPUTER AUTOMATIC CONTROL]- Advanced multi-function LCD control panel with multiple buttons which clearly shows different functions including POWER, RUNNING MODE ADJUSTMENT, CLEAN/SET, ICE THICKNESS/DUTY TIME ADJUSTMENT and ILLUMINATION, helps control ice making process and monitors possible malfunctions.
[COMPLETELY EQUIPPED WITH TOP QUALITY]- Powerful 850W SECOP compressor for fast cooling, low energy consumption, low noise and stable operation. Water filter, dewatering pump, two ice scoops, sealed packaging... All you need is thoughtfully provided. Stainless steel plus ABS construction enables it to be sturdy and robust.
[WIDELY APPLICABLE]- Works great for applications including coffee shops, hotels, bars, KTVs, supermarkets, bakeries, restaurants, cold drink shops, laboratories, schools, hospitals and more. A space saver with adequate storage and powerful performance.
Specifications
Free spare parts:1. Ice scoop 2. Two water input pipes, two drain pipes 3. Water filter
You decide the package and transportion way
2D drawing of the ice making machine( Front, side,back)
The head of machine
Ice storage bin
Tecumseh compressor for 380V/50Hz
Copeland compressor for 220V/60Hz/3P
We have 12 patents on the LCD control panel. It is very reliable.
The finished translucent cube ices were made by the ice making machine
Our real production line in workshop
Features of our ice making machine
◆ Advanced LCD tangibly control panel can be controlled by WIFI.
◆ Water-flow design, the capacity can be increased 10% higher than other similar machines.
◆ Anti-dust mesh design,which is removable and easy for cleaning.
◆Oval design of the edges, enhanced durable machine body and 304 stainless steel material design
◆Push-up door type, Space-saving body, Meeting the requirements of small space, Luxury and beauty.
◆Industry-leading copper-nickel evaporator, Shorter freeze and harvest cycle, Full capacity.
◆Front air intake and exhaust, side for hot air spread, easy to clean, enhance the lifetime of machine.
◆Using advanced noise reduction technology to make working noise reduce more than 15%.
◆Overall food-grade PE liner, through the European CE certification, RoHS Test Report.
◆Testing condition:Ambient temp.25℃, Water temp.16℃
◆Application: Supermarket, aquatic product market ,bar, KTV, hotel, coffee shop, factory.ect
Freser cube ice machine are widely used in hotels, restaurants, bars, fast-food shops, supermarkets and cold drink shops, etc.
cube ice machine are highly efficient, energy saving, safe and environmentally friendly and are quickly becoming the most popular choice for clients around the world.
Hot Freon makes the ice peel off; it only takes as fast as 150-180 seconds.
The importation of water drain function makes ice cleaner and crystallizes the ice by draining out the water in the cold water tank.
Evaporator is made of stainless steel SUS304 to meet the sanitary requirements.
2. Product advantage:
a.Easy to operate
b.Stainless Structure
c.Automatic Protection
d.Elegant appearance
b.f .OEM of Italy Scotsman
c.g. provide water filter free of charge
Detailed description of Strong capacity commercial used cube ice machine:
Operation environment :
Ambient temperature2-43°C.Water temperature 2-38°C.Water pressure 0.13Mpa-0.55Mpa
Installation note:
Minimun installation clearance:Top/sides are 25cm,Back is 12cm.
The Maximum output is on this condition:
Ambient temperature 21°C,water temperature 12°C.
Advantages
Why Choose Us?
Product features:
a. high efficiency compressor
b. strong ice-making capacity
c. food grade refrigerants
d. enhanced durable body and stalinless steel cabinet
e. space-saving design,ideal for bar or under-counter application
f. shorter freeze and harvest cycle means quicker ice recovery
g. front air intake and exhaust,side for hot air spread
h. cube ice, with thickness adjustor. clients can adjust it easily
i. efficient after-sales service
j. professional production experience
k. the serialization of products.
Our service:
All product warranty period is 12month, within this time, we will supply broken parts free, but two points have to clarify clear,
Point1. All products do 24hrs rigorous testing before packing, so machine warranty only under the condition of quality problem . If the user improper operation, spare parts is not provided free of charge. Please operate machine correct and follow user manual, if any problem, pls contact us. we will reply you within 24hrs.
Point 2. When you receive goods, if any question, pls contact us asap, during warranty period, spare parts is free, but shipping fee is burden by customer side.
Point 3. The technical service all the time and 24hrs service for you.
Materials:
Materials:Stainless steel 304, Thickness: 0.8mm,
Compressore: Emraco(Italy),Danfoss(Denmark),Aspera(Italy)
Solenoid valve:Saginomiya (Japan).
Accessories:
Primary parts are made by international top manufacturers.
